Technical Parameters of U15
Rack type ：Quadcopter drone
Power category ：electric
Axle spacing ：1300mm
Extended size ：1050*1030*540mm
Folded size ：455*630*540mm
Overall weight：18.5kg
Maximum takeoff weight ：33.5kg
Empty-load range ：75min
Full load ：30min
Maximum load capacity ：15kg
Flight speed ：15m/s
Maximum climbing speed ：5m/s
Maximum descending speed ：4m/s
Wind resistance level ：Level 6 (Gale Force 7)
Navigation method：GPS/Beidou/GNSS + RTK (optional)
service ceilling：5000m (Requires high-altitude propeller blades)
Working temperature:-20~50℃
Communication distance 15km(Without obstruction, without interference)
Positioning accuracy (GPS) ：Horizontal ± 1m, Vertical ± 0.5m
Positioning accuracy (RTK) ：Horizontal ± 0.1m, Vertical ± 0.1m
Intelligent touch-screen remote controller FPV ：Standard
FPV：Standard
GPS ：Standard
RTK：Standard
Detailed parameters can be obtained by contacting the project manager.
