Product technical parameters
Project: Parameter Description
dimensions: 1660x1610x430mm
Folded dimensions: 465x1160x430mm
Wheelbase： 1225mm
Overall weight： 4.5kg
Recommended load： 5kg – 7kg
Maximum takeoff weight： 17kg
Range of flight time： 2 hours
Flight speed： 0 – 20m/s
Landing speed： 0 – 5m/s
Wind resistance performance： 6 levels
Patrol coverage radius： 15km
Practical ceiling： 5000m
Protection level： IP54
Operating temperature： -20°C – 50°C
Camera parameters
Optical Zoom: 10x high-definition optical zoom lens, f = 5.15 ± 5% to 47.38 ± 5% mm
Focusing time: Real-time quick focusing function, focusing time < 1 second
Video output: Network high-definition RTSP output 1080P, video stream local TF storage
HDMI high-definition output 1080P, video stream local TF storage
Field of view (FOV):
D: WIDE 69.5° ± 5% TELE 7.95° ± 5%
H: WIDE 61.5° ± 5% TELE 7.00° ± 5%
V: WIDE 35.0° ± 5% TELE 3.97° ± 5%
Supported modes: 1080P 30fps
thermal imagery
Resolution: 256*192 pixels
Pixel pitch: 12 μm
Type: Non-cooled vanadium oxide infrared thermal imager
Wavelength range: 8 – 14 μm
Thermal sensitivity (NETD): ≤ 65 mk @ 25℃ @ F1.0
Field of view: 7mm lens, FOV: 24 x 18.
Measurement functions: Center point, maximum temperature display temperature function; Supports global temperature measurement
Overall dimensions: 80mm × 118mm × 137mm
Operating environment: -10℃ to +45℃ / 20% to 80% RH
Storage environment: -20℃ to +60℃ / 20% to 95% RH
Main application: Drone aerial photography
Weight: 430 ± 20 grams
