Product technical parameters
Type: Hexacopter
Material: Industrial nylon, carbon fiber
Storage method: Umbrella-like folding
展开 size： 1380*1200*730mm
Folding size： 608*554*690mm
Axle spacing： 1280mm
Net weight of the entire machine (without battery) ： 7.8kg
Maximum take-off weight： 23kg
Empty flight duration： 61 minutes
Maximum wind resistance： 13m/s
Positioning accuracy (GPS)： ≤0.5m
Positioning accuracy (RTK)： ≤0.3m
Maximum flight speed： 20m/s
Maximum descent speed： 6m/s
Material: Industrial nylon, carbon fiber
Storage method: Umbrella-like folding
展开 size： 1380*1200*730mm
Folding size： 608*554*690mm
Axle spacing： 1280mm
Net weight of the entire machine (without battery) ： 7.8kg
Maximum take-off weight： 23kg
Empty flight duration： 61 minutes
Maximum wind resistance： 13m/s
Positioning accuracy (GPS)： ≤0.5m
Positioning accuracy (RTK)： ≤0.3m
Maximum flight speed： 20m/s
Maximum descent speed： 6m/s
Maximum flight altitude: 5000m
Communication range: 15 kilometers (without obstruction)
Waterproof rating: IP43
Operating temperature: -20°C to 60°C
Communication range: 15 kilometers (without obstruction)
Waterproof rating: IP43
Operating temperature: -20°C to 60°C
It supports 5 channels of load at the same time. With a load capacity of 7 kilograms and a front-mounted FPV camera. It adopts a 12S power system and has a 61-minute battery life. The video transmission range is 15 kilometers (without interference), meeting the industry application requirements in various scenarios such as fire fighting, emergency rescue, and environmental monitoring.
